FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 70 -
Transfer manipulation
Actuators:
- Double-acting parallel rod cylinder Ø15, Stroke:100mm (CXSM15-100),
with flow regulators and initial-end of stroke position detectors. Controlled by
5/2 way bistable solenoid valve.
Sensors:
- Reed type magnetic detectors (D-Z73L).
- Photoelectric cell OMRON (E3X-NA41).
- Fiber optic OMRON (E32-DC200).
Electrical control panel:
- Mounted on perforated mesh.
- Accessible terminal plate with supply connections and coded I/Os.
- I/O station: 7 inputs, 5 outputs.
- Supply module: 24V/60W.
- PLC control:
• CPU with digital inputs/outputs.
• Communication module for PLC network connection.
