SMC Networks HRSH250-W*-20 Series

HRX-OM-Q026
Chapter 1 Safety Instructions
HRSH Series 1.4 Product Label
1-3
1.4 Product Label
Information about the product, such as Serial No. and Model No. can be
found on the product label. This information is needed when contacting an
SMC sales distributor.
How to see the serial number Q Z 001 （December 2012）
Q
Z
001
Year
Symbol
Remarks
Month
Symbol
Remarks
Serial no.
2012
Q
Repeated
from
A to Z in
alphabetic
al
order
1
O
Repeated from
O to Z in
alphabetical
order, with O for
January and Z
for
December
－
2013
R
2
P
2014
S
3
Q
↓
↓
↓
↓
Fig. 1-1 Position of the product label
Kind and amount
of refrigerant
Model number
Serial number
* (An example of "HRSH150-A-20-S" model.)
"3~" stands for "3 inter phase".
(IEC 60417-5032-1)

