HRX-OM-Q026
Chapter 3 Transport and Setting Up
HRSH Series 3.3 Installation
3-11
Option A or “Caster Adjuster-foot kit” (HRS-KS001/KS002)
Refer to the Operation Manual for the separately sold accessory for the further details of the swivel
caster and the adjuster foot set.
Fig. 3-5 Installation by adjuster foot
In case of using “Caster Adjuster-foot kit”, be sure to use the adjuster
foot to install on the floor. The adjuster foot is not earthquake-proof.
If necessary make an earthquake-resistant measure on the customer
side.
Lower the adjuster to the level floor
to fix the product in place.
To Next Page
