Chapter 5 System Operation
HRW Series 5.3 Operation Screen
5-9
5.3.10 Maintenance screen
Figure 5-12 Maintenance Screen
Table 5-11 Maintenance Screen
No.
Item
Setting
1
VALVE
OPEN
The facility water solenoid valve is opened forcefully.
CLOSE
The facility water solenoid valve is closed forcefully.
[Tips]
Available only if a solenoid value (optional) is provided.
5.3.11 Option screen
Figure 5-13 Option Screen
Table 5-12 Option Screen
No.
Item
Setting
1
CUSTOM DIO
ON / OFF
Allows the selection of Valid / invalid.
(See “Communication specifications” for details.)
2
TEMP READY
ON / OFF
Allows the selection of valid / invalid of BAND / READY function.
This becomes valid after turning off the power, then supply the power
again.
1
1
2
