PTE-300-V
Sheet 43
− Range: ± 9.999 Hz.
− Resolution:
• 0.1 Hz
• 0.01 Hz
• 0.001 Hz
− Accuracy: ± 1 digit, ± 0.001 Hz of the selected value.
− External frequency reference range: 40 - 70 Hz.
5.2. POWER GENERATORS
a) Three independent power outputs up to 300 V in voltage mode and 8 A in current mode, with
angle phase regulation between 0º and 360º
• Amplitude indicator: 4 digits display LED.
• Available ranges:
− Voltage Mode: 0 - 6.250 V Regulation resolution: 0.001 / 0.01 / 0.1 V
0 - 150.0 V Regulation resolution: 0.1 / 1 / 10 V
0 - 300.0 V Regulation resolution: 0.1 / 1 / 10 V
− Current Mode: 0 - 0.330 A Regulation resolution: 0.001 / 0.01 / 0.1 A
0 - 8.000 A Regulation resolution: 0.001 / 0.01 / 0.1 A
• Accuracy: better than 1 % of the selected value between 10 % and 100 % of the selected
range.
• Power: 100 VA (1 minute) and 50 VA continuously.
• Protection: overload and thermal.
• Output mode: floating, completely isolated of the rest and the ground.
• Output distortion:
− Typical: < 0.5 %
− Maximum: 1 %
• Phase angle regulation: 0 - 359.9º.
• Phase angle regulation resolution:
− Selectable between: 0.1 / 1 / 10 º.
− Accuracy: ± 0.5º of the selected value.
b) The following functions are available for each channel, through front panel controls:
• Selection of 2
nd
value (fault value) while the actual value remains in the output.
• Push-button to step to the above mentioned value.
• This feature exists for amplitudes and phase angles, independent or linked.
