SMC Networks ZSE20A User Manual

-76-
No.PS※※-OMU0003-C
Product No.
ZSE20A
(Vacuum pressure)
ZSE20AF
(Compound pressure)
ISE20A
(Positive pressure)
Display
Unit
3
MPa, kPa, kgf/cm
2
, bar, psi, InHg, mmHg
MPa, kPa, kgf/cm
2
,
bar, psi
Display type
LCD
Number of displays
3-screen display (Main display, sub display x 2)
Display color
1) Main display: Red/Green
2) Sub display: Orange
Number of display digits
Main display: 4 digits (7-segments)
Sub display: 4 digits (Upper 1 digit 11-segments, 7-segments for other)
Operation light
LED is ON when switch output is ON (OUT1, OUT2: Orange)
Digital filter
4
0, 10, 50, 100, 500, 1000, 5000 ms
Environment
Enclosure
IP40
Withstand voltage
1000 VAC for 1 minute between terminals and housing
Insulation resistance
50 MΩ or more between terminals and housing (with 500 VDC megger)
Ambient temperature range
Operation: -5 to 50
o
C, Storage: -10 to 60
o
C
(No condensation or freezing)
Operating humidity range
Operation, Storage: 35 to 85%RH (No condensation)
Standard
UL/CSA(E216656), CE marked (EMC directive/RoHS directive)
Length of lead wire with connector
2 m
1: Value without digital filter (at 0 ms).
2: If the applied pressure fluctuates around the set value, the hysteresis must be set to a value more than the amount of fluctuation or
chattering will occur.
3: This setting is only available for models with the units selection function. Only MPa or kPa is available for models without this function.
4: The response time indicates when the set value is 90% in relation to the step input.
5: Any products with tiny scratches, smears, or variations in the display color or brightness, which does not affect the performance of the
product, are verified as conforming products.
