○Piping/weight specifications
Product No.
M5
01
N01
C4H
C6H
N7H
C4L
C6L
N7L
Port size
M5 x 0.8
R1/8
NPT1/8
-
-
-
-
-
-
One-touch fitting
Straight type
-
-
-
4 mm
5/32
inch
6 mm
1/4
inch
-
-
-
One-touch fitting
Elbow type
-
-
-
-
-
-
4 mm
5/32
inch
6 mm
1/4
inch
Materials in
fluid c
ontact
part
Pressure-sensing part
Silicon
Piping port (Common)
PBT, CB156, heat resistant PPS, O-ring: HNBR
Piping port
-
C3604
(Electroless
nickel
plating),
SUS304,
NBR
POM, SUS304, NBR, C3604
Weight
Body
24 g
34 g
36 g
27 g
28 g
29 g
30 g
30 g
36 g
Lead wire with connector
+39g
○Cable specifications
Conductor area
0.15 mm
2
(AWG26)
Insulator
Outside diameter
1.0 mm
Color
Brown, Blue, Black, White, Gray (5 core)
Sheath
Finished outside diameter
3.5
