-75-
No.PS※※-OMU0006-A
Specification
■Specifications
Product No.
ZSE20B
(Vacuum pressure)
ZSE20BF
(Compound pressure)
ISE20B
(Positive pressure)
Applicable fluid
Air, non-corrosive gas and non-flammable gas
Pressure
spec
.
Rated pressure range
0.0 to -101.0 kPa
-100.0 to 100.0 kPa
-0.100 to 1.000 MPa
Display/Set pressure range
10.0 to -105.0 kPa
-105.0 to 105.0 kPa
-0.105 to 1.050 MPa
Display/Min. setting unit
0.1 kPa
0.001 MPa
Proof pressure
500 kPa
1.5 MPa
Power supply
spec
.
Power supply voltage
12 to 24 VDC10%, ripple max. 10% (p-p)
Current consumption
35 mA or less
Protection
Polarity protection
Accuracy
Display accuracy
2%F.S. 1 digit (at ambient temperature 253
o
C)
Repeatability
0.2%F.S. 1 digit
Analog output accuracy
2.5%F.S. (at ambient temperature 253
o
C)
Analog output linearity
1%F.S.
Temperature characteristics
2%F.S. (25
o
C standard)
Switch output
Output type
NPN or PNP open collector 2 outputs
Output mode
Hysteresis mode, window comparator mode, error output,
switch output off
Switch operation
Normal output, reversed output
Maximum load current
80 mA
Maximum applied voltage
(NPN output)
28 V
Internal voltage drop
(Residual voltage)
1 V or less (Load current 80 mA)
Delay time
1
1.5 ms or less (delay time available for anti-chattering function:
20,100,500,1000,2000 or 5000 ms)
Hysteresis
Hysteresis mode
Variable from 0
2
Window comparator mode
Short circuit protection
Provided
Analog output
Voltage
output
Output type
Voltage output: 1 to 5 V
Voltage output:
0.6 to 5 V
Output impedance
Approx. 1 kΩ
Current output
Output type
Current output: 4 to 20 mA
Current output:
2.4 to 20 mA
Load impedance
Max. lead impedance: 300Ω (at power supply voltage of 12 VDC)
600Ω (at power supply voltage of 24 VDC)
Min. lead impedance: 50 Ω
Auto
-shift
input
Input type
Non-voltage input : 0.4 V or less
Input mode
Select from auto-shift, auto-shift zero
Input time
5 ms or more
