Smeg STA4645 - Adjusting the Upper Rack

Rev 0.0 29
USER INSTRUCTIONS
EN
Adjusting the upper rack
The upper rack can be adjusted in two positions, according to the user’s needs
and according to the height of the dishes in the lower rack.
Proceed as follows:
pull out the right-hand rack guide. Release the corresponding stop (ref. A fi g.
4-15) by turning it 90° towards the outside of the dishwasher;
pull out the left-hand rack guide and release the corresponding stop, just as
you did for the right-hand rack guide;
remove the rack from the guides;
fi t the upper or lower pair of wheels (ref. B fi g. 4-15) into the guides, depend-
ing on the setting required;
return the guide stops to their original positions (ref. A fi g. 4-15).
A
B
•
•
•
•
•
Fig. 4-15
