Rev 0.0 33
USER INSTRUCTIONS
EN
Fig. 5-05
Fig. 5-06
5.4 Cleaning the fi lter unit
Periodically inspect the fi lter unit (ref. A fi g. 5-05) and, if necessary, clean it
under running water (at room temperature), using a stiff brush. To remove
the fi lter, grip the handle, turn anticlockwise and lift upwards;
push the centre fi lter (ref. A fi g. 5-06) from the underside to remove it from
the micro-fi lter;
separate the two parts which make up the plastic centre fi lter by pressing
the body of the fi lter in the zone shown by the arrows (ref. B fi g. 5-06);
remove the centre fi lter by lifting it upwards.
after cleaning, remount the fi lter unit, joining the two parts comprising the
centre fi lter by pushing slightly until they click into place; insert the centre
fi lter into the micro-fi lter (see fi g. 5-06). Reposition the fi lter unit (ref. A fi g.
5-05) into its seat, turning it clockwise until it locks.
A
BB
A
•
•
•
•
•
