Rev 0.0 13
INSTALLATION INSTRUCTIONS EN
If the appliance is not in a niche and can therefore be accessed on one •
side, cover the door hinge area for safety reasons (cutting hazard). Covers
are available as accessories from specialized retailers or from the Technical
Service Centre.
To build in the dishwasher, purchase the • relative kit from specialized retail-
ers or from the Technical Service Centre.
5.1 Leveling
5.1.1 Mounting the feet (only for some models)
Turn the appliance upside-down (see fi g. 5-01).
Tighten the nut (see ref. A fi g. 5-01) onto the threaded pin (see ref. B fi g. 5-01)
of the foot and then fi t the supplied washer; do this on both feet.
Screw the feet onto the appliance until the washers touch the base; the two
feet must be manually adjusted to the same height to prevent excessive differ-
ences in height between one foot and the other.
Put the appliance back on its feet.
TWO PEOPLE WEARING SAFETY GLOVES ARE NEEDED TO TURN
THE DISHWASHER UPSIDE-DOWN.
A
B
Fig. 5-01
