32 Rev 0.0
INSTALLATION INSTRUCTIONSEN
If a gap is created between the control panel and the door panel (ref. A fi g.
5-29), use the supplied strips (ref. B fi g. 5-29) to fi ll it. The number of strips
depends on the size of the gap.
Fig. 5-29
A
B
Position the strips between the control panel and the door panel of the dish-
washer (ref. A fi g 5-30) and fi x them from under the control panel with the
supplied screws (ref. B fi g. 5-30) using a screwdriver. Adjust the strips until a
suitable compromise is reached.
Fig. 5-30
