34 Rev 0.0
INSTALLATION INSTRUCTIONSEN
Make sure the dishwasher door, complete with panel, opens comfortably and
that the base plate (ref. A fi g. 5-33) does not prevent it from opening fully. If the
base plate prevents the door from opening, mark out the section to remove
(see fi g. 5-33), take out the base plate and cut it along the marking using a
compass saw (see fi g. 5-34).
605 mm (24.2”)
A
Fig. 5-33
Fig. 5-34
