SMH Technologies FlashRunner Cube Series - ISP Signal Definitions

Connectors
9
60
ISP Signal Denitions
Color
ISP Connector A
Sites
ISP Connector B
Sites
FR
Signal
Name
Target Signal Description
S1 S2 S3 S4 S5 S6 S7 S8
Brown
A1 A5 A9 A13 A1 A5 A9 A13 SxL01
#W - Write Protect (programmer set to inactive
level while programming the device)
Red
A2 A6 A10 A14 A2 A6 A10 A14 SxL02
CLK - Serial Clock
Orange
A3 A7 A11 A15 A3 A7 A11 A15 SxL03
DO(IO1) - Serial Data Output
Yellow
A4 A8 A12 A16 A4 A8 A12 A16 SxL04
CLOCKOUT
Green
B1 B5 B9 B13 B1 B5 B9 B13 SxL05
#S - Chip select
Blue
B2 B6 B10 B14 B2 B6 B10 B14 SxL06
DI(IO0) - Serial Data Input
Purple
B3 B7 B11 B15 B3 B7 B11 B15 SxL07
#HOLD - Hold (programmer set to inactive level
while programming the device)
Grey
B4 B8 B12 B16 B4 B8 B12 B16 SxPPS
VDD - Target VDD (Programmer can provide a
power supply for the target system)
Black
C1 C2 C3
C5 C6 C7
C9
C10 C11
C13 C14 C15
C1 C2 C3
C5 C6 C7
C9
C10 C11
C13 C14 C15
SxRLY
GND - GND
White
C4 C5 C12 C16 C4 C5 C12 C16 SxGND
RLY - Relay Output
