FlashRunner Cube User’s Manual
10. Specifications
Electrical Specifications
Feature
Value
Maximum Ratings
Power supply voltage 30V
ISP SxL0[1..7] voltage -0.7-6.5V
ISP SxL0[1..7] current ±60mA
ISP SxPPS voltage -0.7-18V
ISP SxPPS current
(*)
380mA
ISP SxRLY voltage -1.0-30V
Low level interface PRJ_SELx, START,
START_ENAx, BUSY, PASS/FAULTx
voltage
-0.7-6.0V
Operating Ranges
Power supply voltage 12-25V
ISP SxL0[1..7] voltage 0-5.5V
ISP SxPPS voltage 1.5-15V
ISP SxPPS current 300mA
ISP SxRLY voltage 0-28V
Low level interface PRJ_SELx, START,
START_ENAx, BUSY, PASS/FAULTx
voltage
0-5.0V
Physical and Environmental
Operating conditions
0-40°C, 90% humidity max (without
condensation)
Storage conditions
-10-60°C, 90% humidity max (without
condensation)
EMC (EMI/EMS) CE, FCC
(*) Current limited, recovers automatically after fault condition is
removed.
