Smith-Root GPP 2.5 - Page 28

25
USER’S MANUAL
www.smith-root.com
APPENDIX
GPP TROUBLESHOOTING
SHORE MODEL (USING KOHLER CH GENERATOR)
Contents
Check Generator AC Voltages ......................................... 26
Test for Continuity and High Voltage Output
.................. 27
Check Connections, Brushes and Exciter Rectier
........ 28
Check Rotor Windings
..................................................... 29
Check Stator Windings
.................................................... 30
Test GPP Control Box
..................................................... 31
Test GPP Control Box- Cont.
.......................................... 32
Flashing the Rotor
............................................................ 33
Building a Test Load
........................................................ 34
5.0 GPP Wiring Diagram
................................................. 35
7.5 GPP Wiring Diagram
................................................. 36
9.0 GPP Wiring Diagram
................................................. 37
APPENDIX
