251061526 Rev. CVULCAN™ Generator Operations/Service Manual
Technical Specifications
Technical Specifications
Input Power
100–240 V~, 50/60 Hz, single phase
Rated Power Input
800 VA
Output Power
Temperature Control Mode: 50 watts
(+/- 20%) into 250 ohms
Power Control Mode: 200 watts (+/- 20%) into
250 ohms
Maximum Open Circuit Voltage
(peak to peak)
Temperature Control Mode: 392 V
Power Control Mode: 1070 V
Operating Frequency
460 kHz (+/- 5kHz)
Waveform
Quasi-sine wave
Fuses
Dual fuses: T6.3AL250V
RF Duty Cycle
Temperature Control Mode:
20 seconds on/10 seconds off
Power Control Mode:
5 seconds on/5 seconds off
Set Temperature Range
15–99° C (in Temperature Control Mode)
Set Power Range
Temperature Control Mode: 1–50 watts
Power Control Mode: 1–200 watts
Operational Modes
Power Up, Stand-By, Ready, Fault
Power Delivery Modes
Temperature Control, Power Control
Dimensions (Height x Width x Depth)
5.5” x 13.8” x 17.9”
(14.0 cm x 35 cm x 45.5 cm)
Weight
25 lbs. (11.4 kg)
Protection
Class I, Type BF Applied Part—defibrillator proof,
IXP0, continuous operation. This equipment is not
suitable for use in the presence of a flammable
anesthetic mixture with air, oxygen, or nitrous oxide.
Environmental Conditions
Transport
and/or Storage
Use
Temperature -20°–60° C
(-4°– 40° F)
10°–35° C
(50°–95° F)
Humidity 20–90%
(no condensation
allowed)
30–75%
Atmospheric
Pressure
500–1060 hPa 500–1060 hPa
