smith&nephew VULCAN - Output Charts

271061526 Rev. CVULCAN™ Generator Operations/Service Manual
Output Charts
Output Voltage vs. Output Control
0
100
200
300
400
500
600
0 20 40 60 80 100 120 140 160 180 200
Power Set (W)
Open Cut
2 Kohms Cut
Open Coag
2 Kohms Coag
Output
V
oltage
Peak
0
40
80
120
160
200
20 40 60 80 100 120 140 160 180 200
2k Ω
1k Ω
500 Ω
200 Ω
100 Ω
50 Ω
25 Ω
13 Ω
Power Output vs. Output Control
Cut Mode
Power
Out (W)
Power Set (W)
