98
Accessories
15-835 TANK RINSING SYSTEM
REF# PART# DESCRIPTION QUANTITY
1 16-961 1" Adapter 1
2 16-962 1" Coupler 1
3 16-864 1" FTP Elbow 1
4 16-158 Close Nipple 1
5 16-150 Double Thread Fitting 1
6 16-172 4" Nipple 1
7 15-834 Tank Rinsing Nozzle 1
8 16-163 Reducer Bushing 1
Drill 1
3
/
4
" hole 5" from outside edge of cover.
Install Tank Rinsing kit as shown, with the Double
Thread Fitting (Ref 5) going into the cover.
Basket Must be removed During Use.
