Smithco Spray Star 2000 - 20-503 CHEMICAL CLEAN-LOAD DRAWING

92
Accessories
20-758 FRESH WATER WASH TANK - FRONT MOUNT
REF# PART# DESCRIPTION QUANTITY
1 20-757 Mount Plate 1
2 HB-516-18-075 Hex Bolt,
5
/
16
- 18 x
3
/
4
4
HWL-516 Lock Washer,
5
/
16
4
HW-516 Flat Washer,
5
/
16
4
3 10-234 Wash Tank 1
4 17-537 Square U-Bolt 2
5 16-158 Close Nipple 1
6 16-151 Elbow 1
7 16-960 Spigot 1
INSTALLATION INSTRUCTIONS
1. Fresh Water Wash Tank mounts on the left side ROPs.
2. Mount the wash tank (Ref 3) onto the mount bracket (Ref 1)using four
5
/
16
x
3
/
4
bolts, washers and lock-
washers (Ref 2). Tighten.
3. Install the nipple (Ref 5), elbow (Ref 6) and spigot (Ref 7)into the bottom of wash tank (Ref 1). Use
thread tape on all threads.
4. Mount the tank ssembly to the left side ROPs with u-bolts (Ref 4). Tighten.
5. Rinse tank with clear water and check for leaks around ttings.
This tank is for fresh clear water ONLY. Do not put chemicals in this tank.
