Smithco Spray Star 2000 - QJS BOTTOM MOUNT NOZZLE ASSEMBLY

Accessories
77
Nozzles are located 20" (51 cm) apart on the right, left, and center tubes.
Nozzles are 20" high o󰀨 ground.
QJS BOTTOM MOUNT NOZZLE ASSEMBLY
REF# PART# DESCRIPTION QUANTITY
1* 20-673-02 E-Chemsaver® 1
2* 20-673-04
3
/
4
" Bottom Mount Nozzle Body 1
3† 18-417 Single Barb 1
4 20-676 Turbo TeeJet Tip 2
5 20-677 QT White Cap and Washer 2
6‡ 18-416 Double Hose Barb 1
Quantity is per nozzle body. For 18' booms multiply quantity by 11.
Quantity is per nozzle body. For 20' booms multiply quantity by 12.
20-673 Double Hose Barb Nozzle (includes * and ‡ item) 8 or 9
20-674 Single Hose Barb Left Orientation (includes * and † item) 2
20-675 Single Hose Barb - Right Orientation(includes * and † item) 2
Nozzles are located 20" (51 cm) apart on the right, left, and center tubes. Nozzles are 20" high o󰀨 ground.
