Smithco Spray Star 2000 - FUEL TANK DRAWING

24
Parts
FUEL TANK DRAWING
REF# PART# DESCRIPTION QUANTITY
1 HB-516-18-100 Hex Bolt
5
/
16
- 18 x 1 3
HNFL-516-18 Flange Whiz-loc Nut
5
/
16
-18 3
2 20-721 1.8 Liter Carbon Canister 1
3 8800-32
1
/
4
" Fuel Hose 32" 2
18-186 Hose Clamp 4
4 8800-17
1
/
4
" Fuel hose 17 1
18-186 Hose Clamp 2
5 8800-14
1
/
4
" Fuel Hose 14" 1
18-186 Hose Clamp 2
6 50-403 In-line Fuel Filter 1
7 8800-3
1
/
4
" Fuel Hose 3" 2
18-186 Hose Clamp 2
8 18-420 45° Hose Barb 2
9 76-471 Electric Fuel Pump 1
10 20-755 Fuel Pump Mount Bracket 1
11 20-696 Tank Plate Strap 1
12 HB-516-18-50 Hex Bolt
5
/
16
- 18 x
1
/
2
1
HNFL-516-18 Flange Whiz-loc Nut
5
/
16
-18 1
13 HB-516-18-150 Hex Bolt
5
/
16
- 18 x 1
1
/
2
2
HNFL-516-18 Flange Whiz-loc Nut
5
/
16
-18 2
14 75-792 Tank Hold Down 2
15 20-695 Tank Plate 1
16 20-692 10Gallon Fuel Tank 1
20-692-02 Gauge 1
42-814-08 Grommet 1
17 20-692-01 Top Draw 1
42-814-07 Top Draw Grommet 1
18 20-694 Cap 1
19 42-814-05 Roll-over Valve 1
42-814-06 Valve Grommet 1
