78
Accessories
NOZZLE ASSEMBLY
REF# PART# DESCRIPTION QUANTITY
1* 16-988 Cap Assembly 1
2* 16-920-06 Diaphragm, EPDM 1
3* Stainless Steel Screw 1
4* Upper Clamp 1
5* 16-920-03 O-ring 1
6* Pivot Pin, Stainless Steel 1
7 Turret, 3-Outlet, Nylon 1
8 O-ring, EPDM 1
9* Plug 1
10* E-clip 1
11 33-538 Cap - White 1
12 33-554 Nozzle Tip - White (XR11008-VS) 1
13 16-800 Viton Gasket 1
14 16-802 Strainer 1
15* O-ring, Teon 2
16* 33-506 Body Assembly (includes all * items) 1
Quantity is per nozzle body. For 20' booms multiply quantity by 12.
Quantity is per nozzle body. For 18' booms multiply quantity by 11.
