Smithco Spray Star 2000 - Page 13

11
Service
WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 20-579 Wire Harness 1
2 13-488 Key Switch 1
3 14-292 Seat Switch 1
4 77-207 Buzzer 1
5 9017 Terminal 2
9018 Seal 2
6 9016 Weather Pack 1
7 33-480 Pressure Switch 1
8 33-084 Magnetic Coil 1
9 33-509 Master Boom Switch 1
10 Right Boom
15-725 Mount Panel End 1
15-727 Rocker - No light 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
11 Left Boom
15-729 Mount Panel Middle 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
15-727 Rocker - No light 1
12 Pump
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-731 Rocker - Amber 1
13 Cruise
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-732 Rocker - Green 1
14 Lights
15-725 Mount Panel End 1
15-782 Non-Lighted Switch, On-None-O󰀨 1
15-727 Rocker - No light 1
15 32-014 Lights 2
16 12-804 Hour Meter 1
17 16-998 Spray Pump 1
18 20-733 10AMP Circuit Breaker 1
8877 Red Circuit Breaker Boot 1
19 20-730 GPS Speedometer 1
20 GPS Antenna (part of speedometer) 1
21 48-147 Negative Battery Cable 1
22 33-216 Battery 1
23 50-323 Red Battery Cable 1
24 50-359 Oil Temperature Light 1
25 Solenoid 1
26 77-261 40 Amp Circuit Breaker 1
8977 Red Circuit Breaker Boot 1
27 76-471 Electric Fuel Pump 1
28 15-814 Weather Pack 1
9018 Seals 2
9017 Male Terminal 2
29 76-633 Fuel Pump WIre Harness 1
30 30-042-06 Relay 1
