Parts
19
NOSE CONE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
27 10-163 Forward Foot Pedal 1
28 48-066 Pedal Grip 1
29 31-049 Button Plate 1
HB-14-20-075 Hex Bolt,
1
/
4
-20 x
3
/
4
2
HNFL-14-20 Flange Whiz-loc Nut,
1
/
4
- 20 2
30 33-509 Master Control Switch 2
HSTP-14-20-075 Machine Screw,
1
/
4
-20 x
3
/
4
4
31 18-169 Adapter 4
32 15-301 Orbitrol 1
33 77-207 Buzzer 1
34 48-187 Stub shaft 1
35 12-804 Hour Meter 1
36 13-488 Ignition 1
37 50-359 Warning Indicator Light 1
