Accessories
87
30-004 FOAM MARKER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 14-291-05 Double Switch Box 1
33-508 Fuse 1
15-506-02 Center Switch 1
14-291-14 Switch 1
2 HB-516-18-175 Hex Bolt,
5
/
16
-18 x 1
3
/
4
(part of machine) 4
HNFL-516-18 Flange Whiz-loc Nut,
5
/
16
- 18 (part of machine) 4
3 Mount Bracket (part of machine) 1
4* 14-291-04 Tank Bracket 2
5 HN-14-20-075 Hex Bolt,
1
/
4
-20 x
3
/
4
2
HBFL-14-20 Flange Whiz-loc Nut,
1
/
4
-20 2
6* 14-291-02 Foamer Tank 1
7* 14-284-02 Cap Assembly 1
8* Blue Tube 1
9* Clear Tube 1
10* 14-291-03 Compressor Only 1
14-291-01 Black Cover 1
* 14-291 Foamer (includes * parts) 1
WIRING PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 14-291-03 Compressor 1
2 15-504-04 Wiring Harness 1
3 14-291-05 Switch Box 1
33-508 Auto Blade Type Fuse 15 amp 1
15-506-02 Switch - middle 1
14-291-14 Switch - outside 1
4 15-509 Power Cable 1
5 33-271 Fuse Block (part of machine) 1
33-508 Auto Blade Type Fuse 15 amp 1
6 15-507 Tubing -Blue
7 15-507 Tubing - White
8 14-699 Male Coupler 1
14-291-09 Blue WIng Nut 1
14-702 Red Nylon Washer 1
9 20-769 Mount Bracket 10
