Product description
Navigate to the “System Control” menu item using the navigator
control on the keyboard ( 13) and select it by pressing
T.
In the “System Control” menu navigate to the “Settings” menu
item and select it by pressing
T. The “Settings” menu is
displayed.
In the “Settings” menu navigate to the “Date/Time” menu item
and select it by pressing
T. The “Date and Time Setting”
dialog is displayed (see Fig. 33).
The “Date and Time Settings” dialog provides you with the informa-
tion explained below:
Item Description
Time Time in hours, minutes and seconds
Date Year, month and day
Time zone List of continents and several cities on these
Important!
Move between adjacent items in screen menus or win-
dows by directing the navigator up or down.
If you direct the navigator to the right or to the left, you
change the entries or call up a selected menu item or
function.
Make the desired modifications and press
T to apply the
changes and exit or
U to discard your changes.
General settings
The “General Settings” dialog gathers information of the local sta-
tion such as: Station name, serial number, machine id, location,
etc. Depending on your access rights you are allowed to view only
or modify them. By default the local operator has got read-access
only.
The navigation tree in Fig. 34 shows a quick overview how to navig-
ate to the “General Settings” dialog.
Press the
8 key to open the main menu (see Fig. 22).
Navigate to the “System Control” menu item using the navigator
control on the keyboard ( 13) and select it by pressing
T.
In the “System Control” menu navigate to the “Settings” menu
item and select it by pressing
T. The “Settings” menu is
displayed.
95591706 11/02/2010 © smiths detection proprietary information
Fig. 34: Navigation tree to the “General Setting”
dialog
8 Main Menu
$ System Control
$ Settings
$ General
$ General Settings
Fig. 33: “Date and Time Settings” dialog
28
