Annex A
In the event of the image result not being acceptable, a system set-
up should be carried out by a suitably trained technician.
Test card example images
Fig. 87 shows an image where the test card is out of focus. The test
card has been placed too far away from the flat scanning panel.
Fig. 88 shows an image where the test card has been placed at an
incorrect angle to the flat scanning panel.
Fig. 89 shows an image where the test card has been positioned
correctly.
95591706 11/02/2010 © smiths detection proprietary information
Fig. 87: Image with test card too far away
Fig. 88: Image with test card at incorrect angle
Fig. 89: Image with test card positioned
correctly
60
