26
EEWB332B
8.2 WEIGHT UNIT T
OGGLE MODE
Setting the basic weight unit: oz/grams
Select this mode to change the unit of measure of the
weight before or after carrying out a balancing operation.
• Press the “MODE” key until the weight units
indicator flashes. The “oz” indicator will start
fl ashing.
• The display will now look like Figure 31b.
• Press Return.
The weight setting status now calculates weights using
a different unit of measure (from grams to ounces or
from ounces to grams).
The program returns to the main menu.
8.3 DIMENSION UNIT TOGGLE MODE
Setting the basic unit of measure for diameter and
width: inches/mm
Se
lect this mode to change the unit of measure of
the diameter and width before or after carrying out a
balancing operation.
• Press the “MODE” key until the dimensional units
indicator blinks.
The “mm” indicator will start fl ashing.
The display should now appear as shown in Figure 31c.
Note: The operator can now select the units in steps
of 1 mm if the mm mode has been selected.
• Select return.
The state of the diameter and width dimension units
will toggle (inch to mm, or mm to inch).
Note: The unit is set to default to inches.
Offset is always measured and shown in millimeters.
The program returns to the main menu.
8.4 ANTI-SLIP FUNCTION
On wheels with a limited weight, slip specifi cations
may make
it impossible to perform a balance run at the
normal measuring speed.
This feature is intended to alert when wheels are not
well clamped on the shaft. There may be a false error
with very light wheels or bare rims.
This function may be disabled for a single balance run:
Hold the Enter key down while the wheel guard is lowering.
Figure 31b
Figure 31c
