Snapper E250816BE

21
RAILS, LIFT ARMS, CAM LIFT
(28” & 33” Models) (Series 18)
ITEM PART NO. DESCRIPTION
1 4-1389 ARM, Rear Lift (25” Deck Only)
2 1-6122 ROD, Leveling
3 4-2649 WELDMENT, Quadrant,5 Position
4 2-4914 SPRING, Extension
5 2-4878 LEVER, Lift
6 3-1838 BRACE, Top
7 3-1855 GUIDE, Belt
8 3-4918 RAIL, Left Hand
9A 3-6430 RAIL, R.H. (25” Deck)
9B 4-3848 RAIL, R.H. (28”, 30” & 33” Decks)
10 9-0324 SCREW, 3/8-16 x 1” Hex
Washer Self-Tap
11 4-0685 ARM, Front Lift, Adjustable (28”,
30 & 33” Decks)
12 2-2717 ROD, Support (Front Lift Arm to
Front End)
13 1-7847 SNAP RING, 7/16” External
14 3-3008 ARM, Leveling (25” Deck)
15 2-3658 GRIP, Height Adjustment Lever
16 9-1001 SCREW, 5/16-18 x 5/8” Truss
Head Self-Tap (Torx) (2)
17 9-0365 PIN, 1/8 x 3/4” Cotter
18 2-5049 HUB, Deck Lift
19 2-6394 COVER, Height of Cut
20 9-0854 NUT, 3/8-24 Hex Nyloc
21 9-1138 SCREW, 3/8-16 x Hex Washer
Self-Tap (6)
22 9-0361 SCREW, 5/16-18 x 5/8” Hex
Washer Self-Tap
23 9-1164 BOLT, 5/16-24 x 1-5/8” Tapered
Axle
24 9-0480 NUT, 5/16-24 Hex Flange Lock
25 1-3550 PIN, 3/16 x 1” Roll
26 1-2067 RING, Red (2)
27 2-7429 CABLE, Rear Deck (25” Deck)
28 2-2112 RING, White (2) (25” Deck)
29A 2-4762 BRACKET, Deck Lift (25” Deck
Only!)
29B 3-4695 BRACKET, Lift Assist (28”, 30” &
33” Decks)
ITEM PART NO. DESCRIPTION
30 3-2997 ARM, Front Lift-Left (28, 30” &
33” Decks)
31 3-4213 PIVOT, Leveling
32 9-1084 SCREW, 1/4-20 x 3/4” Hex
Washer Self-Tap
33 9-0844 PIN, 3/16 x 3/4” Roll
34 1-9410 SPRING, Latch (Black)
-- 3-5669 SPRING, Latch (Purple)
35 4-1470 WELDMENT, Latch
36 2-6286 GRIP, Lift Latch
37 1-1021 PIN, 1/4 x 1-1/4” Clevis
38 9-0360 PIN, 1/16 x 3/4” Cotter
39 9-0753 PIN, 3/16 x 1-1/2” Cotter
40 9-0858 SCREW, 5/16-18 x 1/2” Hex
Washer Self-Tap
41 9-1016 SCREW, 1/4-20 x 5/8” Hex
Washer Self-Tap
42 9-0606 BOLT, 5/16-18 x 5/8” Hex Flange
Lock (3)
43 9-0585 NUT, 5/16-18 Hex Flange Lock(3)
44 9-0122 WASHER, 3/8” Flat
45 4-1627 WELDMENT, Rear Lift Arm
(28”, 30” & 33” Decks)
46 1-2068 RING, Blue
47 2-8200 SWIVEL
48 2-8021 COVER, Chain
49 9-1503 HAIRPIN, 3/32 x 1-1/2”
50 2-8728 ADJUSTER, Chain (2)
51 9-0584 BOLT, 1/4-20 x 1/2” Hex Flange
Lock
52 9-0583 NUT, 1/4-20 Hex Flange Lock
53 3-5787 ECCENTRIC, Height-of-Cut
54 9-0357 COTTER-PIN, 3/16 x 3/4”
55 3-2243 ANCHOR
56 9-0233 SCREW, 5/16-24 x 3/4” Hex
Head Cap, Grade 5 (2)
57 9-0391 WASHER, 5/16 Internal Tooth
Lock (2)
58 9-0223 NUT, 5/16-24 Hex (2)
59 5-3923 ASSEMBLY, Clutch Plate
R. E. RIDER (EURO) SERIES 16 & 18 MANUAL No. 06103
