MAIN CASE (Hinged Seat Mount)
ITEM PART NO. DESCRIPTION
1 4-2700 CASE, Main (13 HP Briggs)
-- 4-2702 CASE, Main (14 HP Kohler)
2 3-6367 BUMPER, Rear
3 3-7285 FENDER, Left Hand (See page
12 for related parts) (Briggs)
-- 3-7958 FENDER, Left Hand
(Kohler Engine)
4 2-8990 COVER, Battery
5 1-0969 NUT, 5/16-24 Hex Flange Lock
6 2-8989 COVER, Switch
7 3-4299 WING, Rear (Models 28” & 33”
Only!) (2)
8 9-0585 NUT, 5/16-18 Hex Fl. Lock (2)
9 9-0793 SCREW, 5/16-18 x 3/4” Hex
Washer Self-Tap (4)
10 2-3676 LINK, Shift (Long)
11 4-1384 ARM, Shift
12 3-3799 BRACE, Cross
13 1-1018 LINK, Shift (Short)
14 9-0196 NUT, 5/16-18 Hex (2)
15 4-0598 ARM, Shift Handle
16 1-0754 SPRING, Shift Handle
17 4-1232 DETENT, Shift
18 4-0599 HANDLE, Shift
19 2-3354 SWITCH, Seat
20 2-3656 KNOB, Shift Handle
21 3-4724 BRACKET, Switch
22 2-2509 BUSHING, Pilot
23 9-0391 WASHER, 5/16 Internal Tooth
Lock
24 9-0037 PIN, 3/32 x 3/4" Cotter
25 2-3914 PIN, 1/4 x 1-3/4" Tapered
Clevis
26 1-9245 BUSHING, Nylon
27 3-1036 WASHER, Thrust (2)
28 1-9246 BUSHING, Nylon (2)
29 9-0361 SCREW, 5/16-18 x 5/8" Hex
Washer Self-Tap (13)
ITEM PART NO. DESCRIPTION
30 1-2652 CLIP, Wire (7/16”)
31 2-7972 DRAIN, Oil (1/4 Turn) (Kohler)
32 7-7692 BOLT, M8-1.25 x 25mm, Self-
Tap (Kohler)
33 9-1272 FASTENER, 1/4 x 3/4 Ratchet
(6)
34 9-1506 SCREW, 5/16-18 x 1-1/2" Hex
Washer Self-Tap (4)
35 9-1513 SCREW, 5/16-24 x 1-3/4" Hex
Head Cap, Grade 5 (4)
36 1-1791 RETAINER, 5/16 Bolt (4)
37 9-1296 WASHER, 5/16" Flat (4)
38 9-1315 WASHER, 5/16" Split Lock (8)
39 9-1297 NUT, 5/16-24 Hex (8)
40 9-1080 SCREW, #10-24 x 1/4”Hex
Washer Self Tap (2)
41A 3-6419 GUIDE, Belt (33” Kohler)
41B 3-5971 GUIDE, Belt (28” Briggs)
42 9-0238 SCREW, 5/16-24 x 1” Hex
Head Cap, Grade 5 (4)
*43 3-4093 PLATE, Engine
44 2-8200 SWIVEL (2)
45 3-4664 PLATE, Seat
46 2-8656 PIN, Hinge
47 9-0360 PIN, 1/16 x 3/4”, Cotter
48 2-8540 CUSHION
49 2-8657 SPRING, Seat O.P.C.
50 9-0999 SCREW, 1/4-20 x 5/8” Self-
Tap, Truss Head, Torx
51 2-2486 DRAIN, Oil (Briggs)
52 9-1294 WASHER, 9/32” I.D. x 5/8”
O.D.
53 9-1503 HAIRPIN, 3/32 x 1-1/2” (2)
54 9-0206 SCREW, 5/16-18 x 3/4” Hex
Head Cap, Grade 5 (2)
* NOTE: ITEM 43 IS USED ON 14 HP KOHLER
ENGINES ONLY!
