HARDWARE BAGS
HARDWARE BAG 6-1792 (Used on Models: E331416KVE & E331518KVE)
HARDWARE BAG 6-3049 (Used on Models: E250816BE, E281016BE, E281216BE and E281318BE)
R. E. RIDER (EURO) SERIES 16 & 18 MANUAL No. 06103
1-1024 (2)
PLUG
1-1024 (2)
PLUG
2-8659 (2)
KNOB
2-3671
COVER
2-3667
SLEEVE,
STEERING
SHAFT
1-3862
ROLL PIN
1-3849 (2)
SPACER
1-3849 (2)
SPACER
1-3862
ROLL PIN
2-3667
SLEEVE,
STEERING
SHAFT
2-3671
COVER
2-8659 (2)
KNOB
9-1297 (2)
5/16” NUT
9-1515
3/16 x 1-1/2”
COTTER PIN
9-1038 (2)
5/16 x 1/2”
SCREW
9-0372 (2)
1/4” LOCKNUT
9-0372 (2)
1/4” LOCKNUT
9-1038 (2)
5/16 x 1/2”
SCREW
9-1515
3/16 x 1-1/2”
COTTER PIN
9-1315 (2)
5/16” SPLIT
LOCKWASHER
9-1514 (2)
3/8” FLAT
WASHER
2-7172 (2)
1/4 x 5/8” SCREW
1-3321 (2)
BUSHING
9-1516
5/32 x 1”
COTTER PIN
