ST O R A G E4. 3.
Storage temperature: -25 to 70°C,
Storage humidity: from 10% to 90%.
HA N D l I N G4. 4.
The equipment must be handled with care. Damage may be caused if dropped or
subjected to severe impacts.
EN V I R O N m E N T A l CO N D I T I O N S4. 5.
The ASYS TRANSFER SWITCH must be installed as rack mount or on a at horizontal
surface and in an area protected from temperature extremes, water and humidity
and the presence of conductive powder or dust.
DO NOT stack units and do not place any objects on top of a unit.
RA C k mO U N T I N G4. 6.
Taking into consideration that the ASYS is mounted into a cabinet, it is necessary that
the cabinet to be capable of supporting the unit with corresponding rails or angles.
ASYS scope of supply contains two angles for xing the ASYS into a 19 inch rack or
into a cabinet with 19 inch inner design.
Option: Also ASYS vertical mounting is possible.
Rack Mounting
Vertical Mounting
