socomec Asys 16 A Transfer System User Manual

ASYS
16 A Transfer System
ITALIANOENGLISH
12 IOMASY160810-GB_00
CO m m U N I C A T I O N S7. 3.
Dry Contact (DB-9, pin type)
PIN N°. Denition
PIN 4 Input Mains 1 (OK / NG)
PIN 8 Input Mains 2 (OK / NG)
PIN 1 Over Temperature
PIN 7 Overload
PIN 9 SUM Alarm
PIN 5 Common
mE C H A N I C A l fE A T U R E S7. 4.
Items Specication
Dimension W = 430mm D = 315mm H = 44mm (1U)
Weight 5kg
Packaging sizes W = 585mm D = 425mm H = 184mm
Structure Rack Mount Unit (1U)
Material Metallic Case
Colour Pantone 432C
EN V I R O N m E N T7. 5.
Items Specications
Operating temperature 0 to 40 °C
Storage temperature -25 °C to 70 °C Continuous
Storage humidity 10% to 90%
Operation humidity 20%to 85% No condensing
Operation Altitude ≤ 1000m (without downgrading)
Audible noise < 25dBA
Cooling Natural Cooling
IP Protection IP 30
