SA f E T y ST A N D A R D S7. 6.
EN62310-1. (With CE Mark)
EmC ST A N D A R D7. 7.
EMI IEC62310-2, C1
EMS
IEC61000-4-2 level 3
IEC61000-4-3 level 2 (Lab.)
IEC61000-4-4 level 2
IEC61000-4-5 level 3
IEC 61000-2-2 LF Immunity
IEC61000-4-6 level 2 (Lab.)
IEC61000-3-2 Harmonic (Lab.)
IEC61000-3-3 Flicks *
* For ASYS 16A-230 only.
OV E R C U R R E N T7. 8.
Overload: –
105 to 125% (20A) = 45 sec: transfer is possible
126 to 150% (24A) = 27 sec: transfer is possible
151 to 210% (33.6A)= 5 sec: transfer is possible
211 to 300% (48A) = 2 sec: transfer is not possible
Output short-circuit : –
Complete protection is provided by the input FUSE subject to its operating charac-
teristics.
