socomec Asys 16 A Transfer System User Manual

ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00 11
TE C H N I C A l DA T A7.
IN p U T / OU T p U T f E A T U R E S7. 1.
ASYS 16A-120 ASYS 16A-230
INPUT
Nominal voltages 120V 220/230/240V selectable
Voltage acceptance window
Nominal +/- 12%* to +/- 20% adjustable**
Working range voltage 80 ~ 145Vac 160 ~ 290Vac
Nominal frequency
50/60 Hz auto sensing
acceptance +/- 15%
Current 16 Amps
OUTPUT
Voltage range same as input
Nominal frequency same as input
Current 16 Amps
Typical Transfer time 6ms
Maximum Transfer time <= 15ms
* = default
** = on demand
CO N N E C T I O N7. 2.
ASYS 16A-120 ASYS 16A-230
INLET
Power cord
AWG12X3C/20A
2 x IEC 320-C20
OUTLET
4 x NEMA 5-20R
1 x IEC 320-C19
2 x 3 x IEC 320-C13
