socomec COUNTIS M43 - Page 30

- 26
-
30023
Phase 3 volt amps.
4 Float VA 00 16 √ X X
30025
Phase 1 Reactive Power
4 Float VAr 00 18 √ X √
30027
Phase 2 Reactive Power
4 Float VAr 00 1A √ X X
30029
Phase 3 Reactive Power
4 Float VAr 00 1C √ X X
30031
Phase 1 power factor (1).
4 Float None 00 1E √ X √
30033
Phase 2 power factor (1).
4 Float None 00 20 √ X X
30035
Phase 3 power factor (1).
4 Float None 00 22 √ X X
30037
Phase 1 phase angle.
4 Float Degrees 00 24 √ X √
30039
Phase 2 phase angle.
4 Float Degrees 00 26 √ X X
30041
Phase 3 phase angle.
4 Float Degrees 00 28 √ X X
30043
Average line to neutral volts.
4 Float V 00 2A √ X X
30047
Average line current.
4 Float A 00 2E √ √ √
30049
Sum of line currents.
4 Float A 00 30 √ √ √
30053
Total system power.
4 Float W 00 34 √ √ √
30057
Total system volt amps.
4 Float VA 00 38 √ √ √
30061
Total system VAr.
4 Float VAr 00 3C √ √ √
30063
Total system power factor (1).
4 Float None 00 3E √ √ √
30067
Total system phase angle.
4 Float Degrees 00 42 √ √ √
