5. MIMIC PANEL
5.1.3. Display menu
This paragraph describes the menus available on the mimic panel and their functions.
The displays are organised into menus and submenus as shown in the diagram:
• to access a menu press the ENTER key.
• To return to the higher level press ESC key.
• Use the and keys to scroll the information available at a particular level.
FIRST LEVEL SECOND LEVEL THIRD LEVEL
MAIN ALARMS
MEASUREMENTS
COMMANDS IMMEDIATE COMMANDS
EXTENDED COMMANDS
PARAMETERS UPS CURRENT DATA
SERVICE UPS SETTING
CIM ALARMS CODE
WARRANTY CODE
To Next Page
