MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
5. MODBUS UPS DATA ACCESS
5.1 Modbus generic table
Generic address
Length (in 16 bits
word)
Table Description Type Access
0x0001 15 CONFIGURATIONS LIST OF CONFIG Values Read
0x0010 10 SERIAL NUMBER STRING ASCII Read
0x001A 10 SOCOMEC REF
SOCOMEC RANGE
NAME
ASCII Read
0x0024 6 USER DEVICE REF CUSTOMER REF ASCII Read
0x002A 6
USER DEVICE
LOCATION
CUSTOMER LOCATION ASCII Read
0x0030
6+2
(for parallel system)
STATUS UPS STATUS Bits Read
0x0038
6+2
(for parallel system)
ALARMS UPS ALARMS Bits Read
0x0040 80 MEASUREMENTS LIST OF VALUES Values Read
0x00C0 7 MEASUR. CTRL MGNT
BIT = 1 = MEAS.
MANAGED
Bits Read
0x00C7 2 PERMISSONS
BIT = 1 CONTROL
ENABLED
Bits Read
0x00C9 2 CONTROLS 1 BIT = 1 CONTROL Bits Write
0x00CB 4 UPS CLOCK MSB/LSB FORMAT Values
Read/
write
Detail of data type:
Values: 1 word = 16 bit integer: value range: 0 to 65535 or -32768 to +32768
format of values is described in the measurements table.
ASCII: 1 word = 2 characters: MSB = 1st character ASCII code, LSB = 2nd character ASCII code
Bits: 1 words = 16 binary info (Status or Alarms) bit = 1 means info ON/YES, 0 = OFF/NO
Bit 0 = 1st data (S000 or A000, according to address)
