MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
6.6 UPS status table, starting from 0x0030
For Modular Units the Unit table (0x10nn) and UPS table (0x00nn) have the same data.
MODULYS GP STATUS
Address Bits Acronym Description
0x0030
b00 S000 Load protected by Inverter
OUTPUT STATUS
b01 S001
b02 S002 Load supplied by automatic Bypass
b03 S003 Load supplied by Maintenance Bypass
b04 S004 Load OFF
b05 S005
b06 S006 In eco mode
FUNCTIONING MODE
b07 S007 Energy saver
b08 S008
b09 S009 Service Mode
b10 S010
b11 S011 Operating
DEVICE STATUS
b12 S012 Available
b13 S013 On Standby
b14 S014 Isolated
b15 S015 Maintenance Alert
0x0031
b00 S016 Output Breaker closed
DEVICE ENVIRONMENT
b01 S017 Maintenance Bypass closed
b02 S018
b03 S019
b04 S020
b05 S021
b06 S022
b07 S023 Gen set ON
b08 S024
b09 S025
b10 S026 Automatic Start in progress
PROCEDURES
b11 S027 Maint. Bypass procedure in progress
b12 S028 UPS OFF procedure in progress
b13 S029
b14 S030
b15 S031 Alarm Ack. request
0x0032
b00 S032 Battery OK
BATTERY
b01 S033 Battery charged
b02 S034 Battery Test in progress
b03 S035 Battery Test scheduled
b04 S036 Battery charging
b05 S037 Battery Test interrupted
b06 S038 Floating Voltage reduced
b07 S039
b08 S040
DC STORAGE SYSTEM
b09 S041
b10 S042
b11 S043
b12 S044
b13 S045
b14 S046
b15 S047
