MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
6.4 Unit confi guration table, starting from 0x1000
Address Acronym Description Value Remarks
0x1001 T000
UPS installation code and
Device type
MSB = 8 for modular lsb = 1 for Unit
0x1002 T001
Number of devices in level
-1
1 to 15 1 to 8 modules
0x1003 T002
Position of present
devices
b00 Module 1 present
b01 Module 2 present
b02 Module 3 present
b03 Module 4 present
b04 Module 5 present
b05 Module 6 present
b06 Module 7 present
b07 Module 8 present
b08
b09
b10
b11
b12
b13 bypass module
b14
b15
0x1004 T003 Device number 1 to 15 1 to 8
6.5 UPS reference table, starting from 0x0010
Address Acronym Description
Value
Remarks
Length Number of ASCII char.
0x0010 I000 SERIAL NUMBER 10 20
MSB = first char of
string
0x001A I001 SOCOMEC REFERENCE 10 20
MSB = first char of
string
0x0024 I002
USER DEVICE
REFERENCE
612
MSB = first char of
string
0x002A I003
USER DEVICE
LOCATION
612
MSB = first char of
string
