MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
6.7 Additional UPS status table, starting from 0x0034
MODULYS GP STATUS
Generic ad-
dress
Bits Acronym Description
0x0034
b00 S064 Board Slot 1 present
OPTIONS
b01 S065 Board Slot 2 present
b02 S066
b03 S067
b04 S068
b05 S069
b06 S070
b07 S071
b08 S072 Programmable S072
CUSTOM IN / OUT
b09 S073 Programmable S073
b10 S074 Programmable S074
b11 S075 Programmable S075
b12 S076 Programmable S076
b13 S077 Programmable S077
b14 S078 Programmable S078
b15 S079 Programmable S079
0x0035
b00 S080 Programmable S080
CUSTOM IN / OUT
b01 S081 Programmable S081
b02 S082 Programmable S082
b03 S083 Programmable S083
b04 S084 Programmable S084
b05 S085 Programmable S085
b06 S086 Programmable S086
b07 S087 Programmable S087
b08 S088 Programmable S088
b09 S089 Programmable S089
b10 S090 Programmable S090
b11 S091 Programmable S091
b12 S092 Programmable S092
b13 S093 Programmable S093
b14 S094 Programmable S094
b15 S095 Programmable S095
These bits can be programmed for specific use. The combination to activate bits considers the standard Modbus
status and alarms, and also external inputs or output position of relays.
Each bit can be programmed through the Maintenance Software.
