socomec MASTERYS GP4 Series User Manual

33EN
MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
7.7 UPS MEASUREMENTS TABLE, starting from 0x0040
NOTE!
In order to see if a measurement is supported/managed, use the addresses between 0x00C0-
0x00C5 in read access.
ITYS PRO Measurements Formats
Check avail-
ability
Address Acronym Description Units 0x000E = 0 0x000E = 1
0x0040 M000 Output load rate % ### ###
OUTPUT
0x00C0
0x0041 M001 Output load rate L1 % ### ###
0x0042 M002 Output load rate L2 % ### ###
0x0043 M003 Output load rate L3 % ### ###
0x0044 M004 Output Apparent Power kVA ## ### # ###.#
0x0045 M005 Output Active Power kW ## ### # ###.#
0x0046 M006 Output current L1 A ## ### # ###.#
0x0047 M007 Output current L2 A ## ### # ###.#
0x0048 M008 Output current L3 A ## ### # ###.#
0x0049 M009 Output neutral current A ## ### # ###.#
0x004A M010 Output voltage L1 V ### ###
0x004B M011 Output voltage L2 V ### ###
0x004C M012 Output voltage L3 V ### ###
0x004D M013 Output frequency Hz ##.# ##.#
0x004E M014
0x004F M015 Ambient Temperature °C ##.# ##.#
0x0050 M016 Battery voltage string + V # ### ###.#
BATTERY
0x00C1
0x0051 M017 Battery voltage string - V # ### ###.#
0x0052 M018 Battery current string + A ## ### # ###.#
0x0053 M019 Battery current string - A ## ### # ###.#
0x0054 M020
0x0055 M021
0x0056 M022 Battery capacity % ### ###
0x0057 M023 Battery capacity Ah ## ### # ###.#
0x0058 M024 Bat. remaining backup time Mn ### ###
0x0059 M025 Time on battery s ### ###
0x005A M026 Battery temperature °C ##.# ##.#
0x005B M027 Battery temperature average °C ##.# ##.#
0x005C M028 DC Storage voltage V # ### ###.#
0x005D M029 DC Storage temperature °C ##.# ##.#
0x005E M030
0x005F M031
0x0060 M032 Rect. input supply volt. L1 V ### ###
RECT.
0x00C2
0x0061 M033 Rect. input supply volt. L2 V ### ###
0x0062 M034 Rect. input supply volt. L3 V ### ###
0x0063 M035 Rect. input supply freq. Hz ##.# ##.#
0x0064 M036 Rect. input supply volt. U12 V ### ###
0x0065 M037 Rect. input supply volt. U23 V ### ###
0x0066 M038 Rect. input supply volt. U31 V ### ###
