43EN
MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
8.7 System summary table, starting from 0x0036
MODBUS makes it possible to view the units status from the System level through following table:
MASTERYS BC+ & GP4 STATUS
Unit address Bits Acronym Description
0x1036
b00 S096 Unit 1 Operating
b01 S097 Unit 2 Operating
b02 S098 Unit 3 Operating
b03 S099 Unit 4 Operating
b04 S100 Unit 5 Operating
b05 S101 Unit 6 Operating
b06 S102 Unit 7 Operating
b07 S103 Unit 8 Operating
b08 S104
b09 S105
b10 S106
b11 S107
b12 S108
b13 S109
b14 S110
b15 S111
0x1037
b00 S112 Unit 1 Available
b01 S113 Unit 2 Available
b02 S114 Unit 3 Available
b03 S115 Unit 4 Available
b04 S116 Unit 5 Available
b05 S117 Unit 6 Available
b06 S118 Unit 7 Available
b07 S119 Unit 8 Available
b08 S120
b09 S121
b10 S122
b11 S123
b12 S124
b13 S125
b14 S126
b15 S127
