socomec MASTERYS IP+ User Manual

MASTERYS IP+
40-60 kVA 3/1
ENGLISH
IOMMASIPXX07-GB 02 15
UNPACKING AND INSTALLATION
OF THE UNIT
3
3.6.1 Connections of MAINS and AUX MAINS.
3.6.1-1
L1 L2 L3 N
+B2 -B2 -B1 +B1
L11 N1 L14 N4 L12 N2
AUX MAINS
SUPPLY
OUT TRANSFORMER IN TRANSFORMER
MAINS SUPPLY EXT. BATTERY
L11 N11
ø 95÷120 mm
2
ø 95÷120 mm
2
TO
LOAD
L1 L2 L3
ø 25÷35 mm
2
N
3.6.2-1
L1 L2 L3
+B2 -B2 -B1 +B1
L11 N1 L14 N4 L12 N2
AUX MAINS
SUPPLY
OUT TRANSFORMER IN TRANSFORMER
MAINS SUPPLY EXT. BATTERY
L11 N11
ø 95÷120 mm
2
ø 95÷120 mm
2
TO
LOAD
L1 L2 L3
ø 25÷35 mm
2
3.6.2 MAINS and AUX MAINS network connections on UPS without neutral on the main network
Do not combine the main network and the auxiliary network
