MASTERYS IP+
40-60 kVA 3/1
ENGLISH
IOMMASIPXX07-GB 02
49
11
OPTIONS
11.1 KIT GSS (GLOBAL SUPPLY SYSTEM).
This kit optimises generator sizing and control when connected to the UPS input. The generator set performs either
an auto-start up due to the power failure or according to the parameters set by the user on the UPS depending on
how long the power failure lasts or when the remaining battery backup time is reached.
11.2 ISOLATION CONTROLLER.
This device continually checks the transformer isolation, displaying an alarm message on the mimic panel. The man-
agement of the option is possible via ADC card without temperature sensor (refer to paragraph 3.9 “ADC card”)
11.3 REMOTE MIMIC PANEL.
This device monitors and interacts with the UPS through a serial link RS 485 (maximum distance of 175 m) 25 m cable
supplied standard; 50 m cable available as an option). Refer to the relevant user manual for instructions on how to use
the device.
11.4 ACS PCB.
Synchronises UPS output with an external power source (another UPS, even of a di erent brand, generator or transformer).
11.5 SEPARATE AUXILIARY MAINS SUPPLY.
This allows the use of an auxiliary energy source other than the primary mains supply in the event of outage.
11.6 ADC CARD WITH TEMPERATURE SENSOR.
This card can be used to manage up to four normally closed or normally open outputs and up to three digital inputs in
con gurable mode. If more than one ADC card is used simultaneously, the dip-switch con gurations must be di erent.
Secure the card with the appropriate screws.
