FunctionFunction PinPin De󰘰nitionDe󰘰nition NoteNote Digital InputDigital Input
Grounding 7 GND.S Signal GND
DRMs/Logic Interface 8 DRM0 Remoteshutdown
9 DRM1/5 0%powerfeed-in DI 5
10 DRM2/6 50%powerfeed-in DI 6
11 DRM3/7 75%powerfeed-in DI 7
12 DRM4/8 100%powerfeed-in DI 8
Logic interface for VDE-AR-N 4105:2018-11Logic interface for VDE-AR-N 4105:2018-11
This function serves to control and/or limit the output power of the inverter. The inverter
can be connected to a radio ripple control receiver in order to dynamically limit the out-
put power of all inverters within the system. The inverter remains in the reduced power
mode as long as the input is closed.
FunctionFunction PinPin De󰘰nitionDe󰘰nition NoteNote Digital InputDigital Input
Grounding 7 GND.S Signal GND
DRMs/Logic Interface 8 DRM0 Remoteshutdown
9 DRM1/5 0%powerfeed-in DI 5
10 DRM2/6 30%powerfeed-in DI 6
11 DRM3/7 60%powerfeed-in DI 7
12 DRM4/8 100%powerfeed-in DI 8
Remoteshutdown for EN50549-1:2019/VDE ARN 4105:2018-11Remoteshutdown for EN50549-1:2019/VDE ARN 4105:2018-11
The inverter can be disconnected from the grid within 100 ms by an external signal. To
usethisfunctiontheDRM0inputisused.Aslongastheinputisclosed(the15kΩis
connected at the input), the inverter feeds-in. As soon as the input is shorted or opened,
the inverter disconnects from the grid.
Functional description of the terminalFunctional description of the terminal
FunctionFunction PinPin De󰘰nitionDe󰘰nition NoteNote
Grounding 7 GND.S Signal GND
DRMs/Logic Interface 8 DRM0 Remoteshutdown
9 DRM1/5 0%power
42/78 SOFAR 100...125KTLX-G4
