SOFAR 7K~10.5KTLM-G3 User manual
Copyright © Shenzhen SOFAR SOLAR Co., Ltd
Step 4 Connect the AC output cable according to the following requirements:
Connect the yellow and green wires into the keyhole marked with "PE" and
tighten it with an internal cross screwdriver;
Connect the brown wire into the keyhole marked with "L" and tighten it with an
internal cross screwdriver;
Connect the blue wire into the keyhole marked with "N" and tighten it with an
internal cross screwdriver;
Step 5 Fix the AC waterproof cover on the box body with M4 screw
Before installing or removing the AC connector, ensure that the
power grid is disconnected.
