Auxiliary Input
Connector Phone Jack 1/8” (Female, Mono)
Voltage Range Low Range: ±0.16Vpk, High Range: ±1.6Vpk
Routing Automatic upon jack plug connection
Sensitivity Independent value for microphone and auxiliary input
Environmental
Operating Temperature 0°C to 40°C
Storage Temperature -10°C to 50°C
Power
Power 70 mW (Running), 0.3 mW (Sleeping)
Battery Life 48 h (Running), > 6 months (Sleeping)
Battery Charge 5V (USB-powered)
Physical
Dimensions 144mm x 59mm x 18.5mm (5 5/8” x 2 5/16” x 3/4”)
Weight 115g (4 Oz.)
Accessories
Windscreen 35mm x 25mm (12mm hole)
USB Cable 0.9m (3’) A to Micro-B
Carrying Case 213 mm x 183 mm x 62 mm (8.4” x 7.2“ x 2.45”)
Calibration Certificate Tested in accordance with procedures from IEC 61672-3 (2013)
