Soft dB Piccolo-II - Piccolo-II Display Screen; Piccolo-II Overload Indication

1
1 Introduction
Congratulations for purchasing the Piccolo-II Integrating Sound Level Meter. This instrument
provides an innovative and cost effective solution for professional grade acoustical measurement.
1.1 Features
 Precision Integrating Sound Level Meter;
 A, C and Z simultaneous frequency weightings;
 Leq, Lmax, Lmin, Lpeak, SEL,
 10 Percentiles (L1%, L2%, L5%, L8%, L10%, L25%, L50%, L90%, L95% and L99%);
 Large dynamic range: 30 dBA to 130 dBZpk
1
;
 Slow or Fast SPL Time response;
 1/1 Octave spectrum;
 1/3 Octave spectrum
2
;
 400 lines FFT spectrum;
 16 MB memory for up to 198,948 records;
 Auxiliary input for external microphone;
 Large Li-Ion battery for up-to 48h operating time.
1
Using two ranges: Low : 30 dBA to 110 dBZpk, High 46 dBA to 130 dBZpk, at nominal sensitivity
2
1/3 octave spectrum available using Spectrum Analyzer software (Section 8.5)
